FS Advanced Brine Filtration System

For ANS Injectors, it is recommended to use the FS Advanced  Brine Filtration System, equipped with a rotary slot filter and a set of filter sieves of different gradation – Perforated Plate Sieves. Such a system ensures optimal cleaning guaranteeing efficient use of brine and protection for the entire injection system of the machine from contamination. The optional cooling system will ensure a stable injection process against excessive temperature increase (in practice, curing is carried out in the temperature range of 0.5 to 6-8 degrees centigrade.

Features:

→ Multi-stage filtrations system

→ Rotary gap filter

→ Perforated plate sieves two-step filtration system

→ Suction filter

→ Optional pillow-plate bottom cooling system
